Materials · Collection specifications

Aranih · 10-foot program

Board, skin, edgeband and door references from this program.

Board: Custom layup; core and construction must be specified.

HPL / skins: 4 × 8 ft and 4 × 10 ft; 0.9 mm. The later 10-ft page lists 4 × 10 ft.

Edgeband: ABS; 328 ft roll; 1 mm; widths 23 / 43 / 65 mm

Door-program reference: Slab, 3PC, 5PC; prep-for-glass and glass-insert options listed.

Aranih · 10-foot program — catalog technical drawing
Edition 3 · reference 43–44

A catalog-program reference, not a verified current specification or warranty. Confirm the exact construction, finish, dimensions and compatibility before manufacture.
